171050601
Manufacturer:
Wurth Electronics
Mfr.Part #:
171050601
Datasheet:
Description:
Board Mount Modules 10.2mmL×9.9mmW×4.6mmH SMD/SMT Current - Output 1:5 A Voltage - Output 1:6 V 86 %
| Parameter | Value |
|---|---|
| Length | 10.16 mm |
| Width | 9.906 mm |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 7 |
| Height | 4.572 mm |
| Packaging | Reel |
| RoHS | Compliant |
| REACH SVHC | Unknown |
| Features | SCP, UVLO |
| Min Input Voltage | 6 V |
| Output Current | 5 A |
| Output Voltage | 6 V |
| Output Type | Adjustable |
| Max Output Current | 5 A |
| Switching Frequency | 812 kHz |
| Max Input Voltage | 36 V |
| Number of Outputs | 1 |
| Output Power | 30 W |
| Current - Output 1 | 5 A |
| Efficiency | 86 % |
| Voltage - Output 1 | 6 V |
| Min Output Voltage | 800 mV |
| Max Output Voltage | 6 V |
Stock: 1092
Distributors
pcbx
pcbxUnit Price$12.34690
Ext.Price$12.34690
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $12.34690 | $12.34690 |
| 10 | $11.42699 | $114.26990 |
| 25 | $11.06966 | $276.74150 |
| 50 | $10.72351 | $536.17550 |
| 100 | $10.38825 | $1038.82500 |
| 300 | $9.79238 | $2937.71400 |
| 500 | $9.23067 | $4615.33500 |
